基于13.5 nm工作波长的缺陷表征技术是突破极紫外(extreme ultraviolet, EUV)掩模制备质量瓶颈的关键基础. 同步辐射光源能产生波长稳定可调谐、洁净无污染的EUV光束, 是开展掩模缺陷表征研究的理想光源. 本文综述了国际知名同步辐射EUV光源掩模缺陷表征平台的工作原理、性能指标及技术优缺点, 深入剖析了结合傅里叶合成照明的离轴波带片全场成像、结合扫描技术与相干衍射成像的叠层衍射成像这两类主流表征方案, 同时指出了掩模缺陷检测和分析一体化、光源微型化、成像技术优势互补的发展趋势. 本文结论不仅为下一代EUV掩模缺陷表征平台设计提供了参考范例, 也为国产化6英寸EUV掩模缺陷表征系统的实际研制提供了一定的工程实践价值.The multilayer structure of extreme ultraviolet (EUV) masks limits the penetration depth of traditional inspection techniques at non-working wavelengths, thus hindering the effective examination of buried phase defects. Developing defect characterization techniques operating at the 13.5 nm wavelength is crucial for overcoming the quality bottleneck in EUV mask fabrication. Synchrotron radiation light source, with their stable EUV wavelength, cleanliness, and high power density, represents an ideal light source for EUV mask defect characterization research. In this work the current state of technology development for mask characterization at the world's four major synchrotron radiation facilities are systematically reviewed. Through comparative analysis, their working principles, technical advantages, and limitations are investigated in depth, and provide a forward-looking discussion on future trends. In response to the specific requirements for EUV mask defect detection and review, this paper discusses the requirements for the next-generation system platform, which integrates deep detection and review functions, develops novel compact light sources, and innovatively combines the advantages of various imaging techniques to improve the numerical aperture (NA) of imaging systems. This aims to achieve a theoretical resolution of over 20 nm, meeting the future demands of the EUV lithography industry for higher NA (>0.55) and shorter wavelengths (6.7 nm). Regarding the prospects of extending synchrotron radiation to industrial applications, a compact synchrotron radiation source, which can be developed on-site in semiconductor facilities, is introduced to accelerate the research and development cycle, while achieving the synergistic integration of imaging technologies. This paper focuses on the application of phase recovery principle of ptychography to Fourier synthesis illumination (FSI), achieving aberration correction in lens-based systems through synthetic aperture extension. In this paper, the working principles, performance benchmarks, technical challenges, and emerging development trends of existing synchrotron radiation-based EUV mask characterization techniques are investigated. It provides an important reference for designing next-generation EUV mask characterization system platforms.
-
Keywords:
- extreme ultraviolet (EUV) mask /
- synchrotron radiation source /
- mask defect inspection and review /
- Fourier synthesis illumination
